G1" Remote Controlled Pulse Solenoid Valves Goyen RCA2574 pulse jet valve

Application : Compressed Air , dust collector services

Size : G1"

Working Pressure : 0,5…8 Bar (3/4”…1 1/2”); 3…8 Bar (2”…3”)

Coil, Tube : Stainless Steel

Body : Aluminum

Seal : NBR, Viton, thermoplastic (3/4”…1 1/2”); NBR, Viton (2”…3”)
  • RCA2574

  • THKPC

  • 8481802190

Availability:

Product Description



Application : Compressed Air , dust collector services

Size : 3/4"..3"

Working Pressure : 0,5…8 Bar (3/4”…1 1/2”); 3…8 Bar (2”…3”)

Coil, Tube : Stainless Steel

Body : Aluminum

Seal : NBR, Viton, thermoplastic (3/4”…1 1/2”); NBR, Viton (2”…3”)

Fluid Temperature : -40°C…120 °C ( with thermoplastic diaphragm ), -10°C…80 °C ( with NBR diaphragm ), -10°C…160 °C ( with Viton diaphragm )

Position : Normally closed

Coil Voltage : 230V, 110V , 48V, 24V , 12V AC ; 110V , 48V , 24V , 12 V DC

QQ截图20240401201410
